Electric Vehicle Data
Battery Capacity % guaranteed under warranty: 70
Battery Capacity in kWh: 16.6
Battery Charging Scenario 1 - Charge Time (Mins): 420
Battery Charging Scenario 1 - Percentage Change: 0-100
Battery Charging Scenario 1 - Power Supply - kW: 2.2
Battery Charging Scenario 2 - Charge Time (Mins): 180
Battery Charging Scenario 2 - Percentage Change: 0-100
Battery Charging Scenario 2 - Power Supply - kW: 7
Battery Charging Scenario 3 - Charge Time (Mins): Not Available
Battery Charging Scenario 3 - Percentage Change: Not Available
Battery Charging Scenario 3 - Power Supply - kW: Not Available
Battery Charging Scenario 4 - Charge Time (Mins): Not Available
Battery Charging Scenario 4 - Percentage Change: Not Available
Battery Charging Scenario 4 - Power Supply - kW: Not Available
Battery Type: Lithium-ion
Charging Port Location: Right Side Rear
Coupler/Connector Type: Type 2
Maximum Charging Rate - kW: 7
Standard manufacturers Battery warranty - Mileage: 80000
Standard manufacturers Battery warranty - Years: 7
Usable Battery Capacity: 14.9
WLTP - EC (kWh/100km) - City: 18.4
WLTP - EC (kWh/100km) - Comb: 24
WLTP - EC (miles/kWh) - City: 3.4
WLTP - EC (miles/kWh) - Comb: 2.6
WLTP - Equivalent AER (km) - City: 71
WLTP - Equivalent AER (km) - Comb: 52
WLTP - Equivalent AER (miles) - City: 44
WLTP - Equivalent AER (miles) - Comb: 32
Emissions - ICE
Standard Euro Emissions: EURO 6
Emissions - PHEV
WLTP - CO2 Weighted (g/km) - Comb: 43
Engine and Drive Train
Compression Ratio: 11.5:1
Cylinders - Bore (mm): 74
Cylinders - Stroke (mm): 86.6
Engine Code: Not Available
Engine Layout: FRONT TRANSVERSE
Fuel Delivery: TURBO DIRECT INJECTION
Fuel Consumption - ICE
EC Directive 1999/100/EC Applies: No
Fuel Consumption - PHEV
WLTP - FC Weighted (l/100km) - Comb: 1.8
WLTP - FC Weighted (mpg) - Comb: 155.8
General
Alternative Fuel Qualifying: Yes
Based On ID: Not Available
Coin Description: TGI PHEV
Did at least one aspect of this vehicle's safety give cause for concern?: No
Insurance Group 1 - 50 Effective January 07: 28A
Manufacturers Corrosion Perforation Guarantee - Years: 6
Manufacturers Paintwork Guarantee - Years: 3
Service Interval Frequency - Months: 12
Service Interval Mileage: 15000
Standard manufacturers warranty - Mileage: 80000
Standard manufacturers warranty - Years: 7
Timing Belt Interval Frequency - Months: Not Available
Timing Belt Interval Mileage: Not Available
Vehicle Homologation Class: M1
Performance
Engine Torque - LBS.FT: 273
Engine Torque - MKG: 37.7
Engine Torque - RPM: 1700
Test Cycles
Emissions Test Cycle: WLTP
RDE Certification Level: RDE 2
Tyres
Tyre Size Front: 235/50 R18
Tyre Size Rear: 235/50 R18
Tyre Size Spare: TYRE REPAIR KIT
Wheel Style: Not Available
Vehicle Dimensions
Height (including roof rails): 1685
Width (including mirrors): 2078
Weight and Capacities
Fuel Tank Capacity (Litres): 37
Gross Vehicle Weight: 2196
Luggage Capacity (Seats Down): 1375
Luggage Capacity (Seats Up): 448
Max. Towing Weight - Braked: 1500
Max. Towing Weight - Unbraked: 750
Turning Circle - Kerb to Kerb: 11.1
