CO: Not Available

HC: Not Available

HC+NOx: Not Available

Noise Level dB(A): Not Available

NOx: Not Available

Particles: Not Available

Standard Euro Emissions: EURO 6

WLTP – CO2 (g/km) – Comb: 189

WLTP – CO2 (g/km) – Comb – TEH: 159

WLTP – CO2 (g/km) – Comb – TEL: 235

WLTP – CO2 (g/km) – Extra High: 203

WLTP – CO2 (g/km) – High: 159

WLTP – CO2 (g/km) – Low: 235

WLTP – CO2 (g/km) – Medium: 178

Automatic Transmission: No

Catalytic Convertor: Yes

CC: 1996

Cooling System: WATER

Cylinder Layout: IN-LINE

Cylinders: 4

Engine Layout: FRONT TRANSVERSE

Engine Make: Not Available

Fuel Delivery: COMMON RAIL

Fuel Type: DIESEL

Gears: 6 SPEED

Manual Transmission: Yes

Number of Valves: 16

Valve gear: DOHC

EC: No

WLTP – FC (l/100km) – Comb: 7.2

WLTP – FC (l/100km) – Comb – TEH: 6.1

WLTP – FC (l/100km) – Comb – TEL: 9

WLTP – MPG – Comb: 32.7

WLTP – MPG – Comb – TEH: 46.3

WLTP – MPG – Comb – TEL: 31.4

Alternative Fuel Qualifying: No

Badge Engine CC: 2.0

Badge Power: 136

Based On ID: Not Available

Battery Volts: 12

Chassis Engine Number: Not Available

Coin Description: Not Available

Coin Gross Vehicle Weight Code: Not Available

Coin Power Output Code: Not Available

Coin Series: Not Available

Coin Wheelbase Description Code: Not Available

Coin Wheelbase Name Code: Not Available

Did at least one aspect of this vehicles safety give cause for concern?: Not Available

Generation Mark: 2

Ghost model for valuation purposes: No

Insurance Group 1: Not Available

Insurance Group 2: Not Available

Manufacturers Corrosion Perforation Guarantee – Years: 12

Manufacturers Paintwork Guarantee – Years: 3

NCAP Adult Occupant Protection %: Not Available

NCAP Child Occupant Protection %: Not Available

NCAP Front/Side Impact – Discontinued February 09: Not Available

NCAP Overall Rating – Effective February 09: Not Available

NCAP Overall Rating – LCV: Gold

NCAP Pedestrian – Discontinued February 09: Not Available

NCAP Pedestrian Protection %: Not Available

NCAP Safety Assist %: 63

Relative Height: H1

Relative Length: L1

Running Cost League Headings: Not Available

Service Interval Frequency – Months: 24

Service Interval Mileage: 25000

Special Edition: No

Special Order: No

Standard manufacturers warranty – Mileage: 100000

Standard manufacturers warranty – Years: 3

Timing Belt Interval Frequency – Months: 120

Timing Belt Interval Mileage: 150000

Vehicle Homologation Class: N1

Vin/Frame No.: Not Available

0 to 62: Not Available

BHP: 136

Engine Power KW: 100

Engine Power RPM: 3250

Engine Torque LBS.FT: 266

Engine Torque MKG: 36.7

Engine Torque NM: 360

Engine Torque RPM: 1500

Top Speed: Not Available

Emissions Test Cycle: WLTP

RDE Certification Level: RDE 2

Alloys?: Yes

Automatic Clutch: No

Plated 3rd Axle: Not Available

Plated 4th Axle: Not Available

Space Saver?: No

Tyre Make: Not Available

Tyre Size Front: 215/65 R16

Tyre Size Rear: 215/65 R16

Tyre Size Spare: FULL SIZE

Wheel Style: Not Available

Wheel Type: 16″ ALLOY

Height: 1968

Height (including roof rails): Not Available

Length: 5050

Load Height: 593

Load Length: 2602

Load Space Width Between Wheel Arches: 1392

Load Width: 1777

Lower Rear Door Width: 1400

Rear Door Height: 1314

Side Load Door Height: 1301

Side Load Door Width: 1030

Turning Circle – Kerb to Kerb: 10.9

Turning Circle – Wall to Wall: 11.6

Upper Rear Door Width: 1400

Wheelbase: 3100

Width (excluding mirrors): 2032

Width (including mirrors): 2275

Boot Capacity Saloons: Not Available

Fuel Tank Capacity (Litres): 55

Gross Train Weight: 5525

Gross Vehicle Weight: 3025

Load Space Volume: 5.8

Luggage Capacity (Seats Down): Not Available

Luggage Capacity (Seats Up): Not Available

Luggage Capacity – 2nd Row Seats Removed: Not Available

Luggage Capacity – 2nd Row Seats Up: Not Available

Luggage Capacity – 3rd Row Seats Down: Not Available

Luggage Capacity – 3rd Row Seats Removed: Not Available

Luggage Capacity – 3rd Row Seats Up: Not Available

Max. Roof Load: 170

Max. Towing Weight – Braked: 2500

Max. Towing Weight – Unbraked: 750

Minimum Kerbweight: 1904

No. of Seats: 3

Payload: 1121

Plated 2nd Axle: 639

Plated Front Axle: 1150

13″ Touchscreen

5G embedded modem

AECS NO SMS/Roll Detect 2G

PAS

Tyre pressure monitor

SYNC 4 – Android Auto/Apple Car Play,advance speech recognition,over the air update capability

Body coloured door mirrors

Body coloured front bumper

Body coloured rear bumpers

Daytime running lights

Dual heated auto fold power exterior mirror

Electric front windows with one touch facility for driver and front passenger

Front splash guards

Low roof line

Quickclear front window defroster

Rear cargo hinged door

Rear splash guards

Tinted glass

Trailer sway control

6 Load compartment tie down loops

Alchol interlock

Courtesy light

Interior grab handle with driver’s sunglasses holder

LED lights

Locking glove box lid

Sensico gearshift knob

Super bright load compartment lights

Seat pack 46 – Transit Custom

Passenger airbag

2 remote keys

Alcohol interlock

Alcohol Interlock wiring preparation pack

Configurable locking 1

Keyless entry and start

Locking wheel lug nut

Power door dead locks

Speed dependant locking

Thatcham category 1 alarm

Thatcham category 1 alarm with power door deadlocks

20L AdBlue tank

ABS

Diesel particulate filter

ESP

Hill launch assist

Traction control

16″ Steel spare wheel

Full wheelcovers
