CO2: 170

HC: Not Available

Standard Euro Emissions: EURO 6

WLTP – CO2 (g/km) – Comb: 200

WLTP – CO2 (g/km) – Comb – Max: 224

WLTP – CO2 (g/km) – Comb – Min: 200

Automatic Transmission: No

Catalytic Convertor: Yes

CC: 1968

Cooling System: WATER

Cylinder Layout: IN-LINE

Cylinders: 4

Engine Layout: FRONT TRANSVERSE

Engine Make: Not Available

Fuel Delivery: COMMON RAIL

Fuel Type: DIESEL

Gears: 5 SPEED

Manual Transmission: Yes

Number of Valves: 16

Valve gear: DOHC

EC: No

EC Combined: 44.1

EC Extra Urban: 48.7

EC Urban: 37.2

WLTP – FC (l/100km) – Comb: 7.6

WLTP – FC (l/100km) – Comb – TEH: 7.8

WLTP – FC (l/100km) – Comb – TEL: 7.1

WLTP – FC (l/100km) – Extra High: 8.7

WLTP – FC (l/100km) – High: 6.6

WLTP – FC (l/100km) – Low: 8.2

WLTP – FC (l/100km) – Medium: 7

WLTP – MPG – Comb: 37.2

WLTP – MPG – Comb – TEH: 36.2

WLTP – MPG – Comb – TEL: 39.8

WLTP – MPG – Extra High: 32.5

WLTP – MPG – High: 42.8

WLTP – MPG – Low: 34.4

WLTP – MPG – Medium: 40.4

Alternative Fuel Qualifying: No

Badge Engine CC: 2.0

Badge Power: 110

Based On ID: Not Available

Chassis Engine Number: Not Available

Coin Description: Not Available

Coin Gross Vehicle Weight Code: Not Available

Coin Power Output Code: Not Available

Coin Series: Not Available

Coin Wheelbase Description Code: Not Available

Coin Wheelbase Name Code: Not Available

Did at least one aspect of this vehicles safety give cause for concern?: No

Exhaust System: CATALYTIC CONVERTER

Front Brakes: VENTILATED DISCS

Front Suspension: MCPHERSON STRUTS

Generation Mark: 6

Ghost model for valuation purposes: No

Hand Brake: REAR WHEELS

Insurance Group 1: Not Available

Insurance Group 2: Not Available

NCAP Adult Occupant Protection %: Not Available

NCAP Child Occupant Protection %: Not Available

NCAP Overall Rating – Effective February 09: Not Available

NCAP Overall Rating – LCV: Gold

NCAP Pedestrian Protection %: Not Available

NCAP Safety Assist %: Not Available

Rear Brakes: VENTILATED DISCS

Rear Suspension: COIL SPRINGS

Relative Height: H1

Relative Length: L1

Running Cost League Headings: Not Available

Service Interval Frequency – Months: 12

Service Interval Mileage: 10000

Special Edition: No

Special Order: No

Standard manufacturers warranty – Mileage: 100000

Standard manufacturers warranty – Years: 3

Steering: PAS RACK AND PINION

This vehicle is classed as a car for VED purposes: No

Vehicle Homologation Class: N1

Vin/Frame No.: Not Available

0 to 62 mph (secs): 15.5

BHP: 110

Engine Power KW: 81

Engine Power RPM: 3200

Engine Torque LBS.FT: 184

Engine Torque MKG: 25.5

Engine Torque NM: 250

Engine Torque RPM: 1250

Top Speed: 102

Emissions Test Cycle: WLTP

RDE Certification Level: RDE 2

Alloys?: No

Automatic Clutch: No

Plated 3rd Axle: Not Available

Plated 4th Axle: Not Available

Space Saver?: No

Tyre Make: Not Available

Tyre Size Front: 205/65 R16

Tyre Size Rear: 205/65 R16

Tyre Size Spare: FULL SIZE

Wheel Style: Not Available

Wheel Type: 16″ STEEL

Front Overhang: 908

Height: 1978

Height (including roof rails): Not Available

Length: 4904

Load Height: 1410

Load Length: 1600

Load Space Width Between Wheel Arches: 1244

Load Width: 1700

Rear Overhang: 993

Side Load Door Height: 1264

Side Load Door Width: 1017

Turning Circle – Wall to Wall: 11.9

Wheelbase: 3000

Width (excluding mirrors): 1904

Width (including mirrors): 2297

Boot Capacity Saloons: Not Available

Fuel Tank Capacity (Litres): 70

Gross Train Weight: 4900

Gross Vehicle Weight: 3000

Luggage Capacity (Seats Down): Not Available

Luggage Capacity (Seats Up): Not Available

Luggage Capacity – 2nd Row Seats Removed: Not Available

Luggage Capacity – 2nd Row Seats Up: Not Available

Luggage Capacity – 3rd Row Seats Down: Not Available

Luggage Capacity – 3rd Row Seats Removed: Not Available

Luggage Capacity – 3rd Row Seats Up: Not Available

Max. Towing Weight – Braked: 2200

Max. Towing Weight – Unbraked: 750

Minimum Kerbweight: 1975

No. of Seats: 5

Payload: 1025

Plated 2nd Axle: 1600

Plated Front Axle: 1550

Child seat anchors ISOFIX and top tether in 2nd row of seats

Cross wind assist

Dimmable illuminated instruments

Driver alert with black and white multi function display plus

eCall emergency system

Electromechanical speed sensitive power steering, height and longitudinally adjustable steering column

Forward collision warning front assist with autonomous emergency braking

Headlight range control

Mobile phone interface

Without voice control

2 USB interfaces type C in dashboard

4 speakers with 2 tweeters and 2 woofers

Composition colour radio with 6.5″ touchscreen

Digital radio reception (DAB+)

Volkswagen app connect

4 stages windshield wiper intermittent control for windshield wipers

Green heat insulating glass

H7 twin halogen headlamps

Heat insulating windshield made of laminated glass

Illuminated steps in passenger/load compartment

Left convex exterior mirror

Rear combination lamps

Rear window with heated insulating glass, heated rear window wiper and washer system

Right convex exterior mirror

Separate daytime running light (permanently switched on while driving)

Tailgate closing with unlatching from the inside

Tailgate with window aperture

Transporter nameplate on the rear fender

Unpainted radiator grille with 2 chrome trims

Without adhesive film

Without trailer hitch

1 12V outlet in dashboard

3 spoke leather wrapped multi function steering wheel

Additional sound deadening measures in cab and passenger compartment

Comfort headliner in cab, hardboard roof trim in passenger and load compartment

Dimming breakaway interior rear view mirror

Dust/pollen filter

Folding grab handles on roof frame

Front seats on the right in 1st row of seat

Glove compartment with illumination

Heavy duty tool kit and jack

Interior plastic loading edge protection

Lashing rings for load restraint system

LED Interior lighting in load and passenger compartment

Medium height for vehicles with window aperture hardboard side trim panels in passenger/load compartment

Rubber floor covering in passenger/load compartment with loading edge protection in rear

Standard lower part dashboard in palladium

Without partition

Without refrigerant

Without seats in 3rd row of seats

Non smoker pack – Transporter

Without storage pack – Transporter

3 point height adjustable seat belts on outer seats cab with electric pretensioners

Driver and front passenger airbag with front passenger airbag deactivation

Power operated child safety lock

Single tone horn

Warning buzzer and light for driver seat belt not fastened

Electronic immobiliser

Wheel bolts without wheel locks

16″ chassis with 16″ brake system

70 L volume fuel tank

Diesel particulate filter

Electronic stability control, ABS, ASR with deactivation button, electronic differnetial lock, hill start assist and brake assist system

Standard anti drum measures

Start/stop system with regenerative breaking

Wheel trims
